Paradox Spectra SP4000 Programming Guide

Magellan / Spectra SP 57
Connecting to WinLoad / BabyWare
Updating Firmware Using WinLoad / BabyWare
To update your system firmware:
1. Connect the product to your computer using a 307USB Direct Connect Interface or CV4USB Converter.
2. Start WinLoad / BabyWare Installer Upload/Download Software.
3. Click the In-Field Programmer button.
4. Verify the product information located in the In-Field Firmware Programmer window.
If the firmware programmer does not automatically detect your control panel, click the Com port settings button and select the
correct Com port. Then click the Refresh Product Info button to connect with the panel.
5. To check for new updates, click the Download Firmware from the web button.
6. From the Select Firmware drop-down box, select the firmware version you wish to install.
or
If you have already downloaded the .pef/.puf file from paradox.com, click the [...] button and select the location of the .pef/.puf file.
7. Click the Update product firmware button.
8. When the download process finishes, the update is complete.
Serial Connector
Computer
containing
WinLoad /
BabyWare
software
307 adapter/
CONV4USB
Converter
4-pin
connector
cable
Standard
DB-9 cable
(9-pin serial
cable)

Paradox Spectra SP4000 Specifications

General

Partitions	2
User Codes	32
Event Buffer	256 events
StayD Mode	Yes
Expandable via Expansion Modules	Yes
Bus	Yes, 4-wire expansion bus
Battery Backup	12V 7Ah
PGM Outputs	2
