Paradox Spectra SP4000

Magellan / Spectra SP 17
*This option applies to all hardwired zones (panel, keypad, ZX8)
Zone Timers (MG Series)
Note that When both ATZ and EOL are enabled, zone speed should not be set below 300ms.
Zone Timers (SP Series)
NOTE: When both ATZ and EOL are enabled, zone speed should not be set below 300ms.
[6] & [7] Supervision Options
[8] Generate supervision on bypassed zone
 No

Yes
[706] General Zone Options
Option OFF ON
[1] Check-in supervision time (except SP4000) 
24 hours
80 minutes
[2] EOL resistors* 
Disabled
 Enabled
[3] Zone Input 1 becomes a 2-wire smoke input (except SP5500/SP4000) 
Disabled
 Enabled
[4] ZX8 ID A (Panel + 1) Input 1 
Zone input
 Tamper input
[5] ZX8 ID B (Panel + 9) Input 1 
Zone input
 Tamper input
[6] ZX8 ID C (Panel + 17) Input 1 
Zone input
 Tamper input
Section MG5000 MG5050 Data Description (Default 060)
[041] Zone 1 (Z1) (Z1) ____/____/____ (000 to 255) x 10ms Hardwire Zone 1 Speed
[042] Zone 2 (Z2) (Z2) ____/____/____ (000 to 255) x 10ms Hardwire Zone 2 Speed
[043] Zone 3 (Z1 ATZ) (Z3) ____/____/____ (000 to 255) x 10ms Hardwire Zone 3 Speed
[044] Zone 4 (Z2 ATZ) (Z4) ____/____/____ (000 to 255) x 10ms Hardwire Zone 4 Speed
[045] Zone 5 (Z5) ____/____/____ (000 to 255) x 10ms Hardwire Zone 5 Speed
[046] Zone 6 (Z1 ATZ) ____/____/____ (000 to 255) x 10ms Hardwire Zone 6 Speed
[047] Zone 7 (Z2 ATZ) ____/____/____ (000 to 255) x 10ms Hardwire Zone 7 Speed
[048] Zone 8 (Z3 ATZ) ____/____/____ (000 to 255) x 10ms Hardwire Zone 8 Speed
[049] Zone 9 (Z4 ATZ) ____/____/____ (000 to 255) x 10ms Hardwire Zone 9 Speed
[050] Zone 10 (Z5 ATZ) ____/____/____ (000 to 255) x 10ms Hardwire Zone 10 Speed
[051] Zone 11 ____/____/____ (000 to 255) x 10ms Hardwire Zone 11 Speed
[052] Zone 12 ____/____/____ (000 to 255) x 10ms Hardwire Zone 12 Speed
[053] Zone 13 ____/____/____ (000 to 255) x 10ms Hardwire Zone 13 Speed
[054] Zone 14 ____/____/____ (000 to 255) x 10ms Hardwire Zone 14 Speed
[055] Zone 15 ____/____/____ (000 to 255) x 10ms Hardwire Zone 15 Speed
[056] Zone 16 ____/____/____ (000 to 255) x 10ms Hardwire Zone 16 Speed
Section SP4000 SP5500 SP6000 SP7000* Data Description (Default 060)
[041] Zone 1 (Z1) (Z1) (Z1) (Z1) ____/____/____ (000 to 255) x 10ms Hardwire Zone 1 Speed
[042] Zone 2 (Z2) (Z2) (Z2) (Z2) ____/____/____ (000 to 255) x 10ms Hardwire Zone 2 Speed
[043] Zone 3 (Z3) (Z3) (Z3) (Z3) ____/____/____ (000 to 255) x 10ms Hardwire Zone 3 Speed
[044] Zone 4 (Z4) (Z4) (Z4) (Z4) ____/____/____ (000 to 255) x 10ms Hardwire Zone 4 Speed
[045] Zone 5 (Z1 ATZ) (Z5) (Z5) (Z5) ____/____/____ (000 to 255) x 10ms Hardwire Zone 5 Speed
[046] Zone 6 (Z2 ATZ) (Z1 ATZ) (Z6) (Z6) ____/____/____ (000 to 255) x 10ms Hardwire Zone 6 Speed
[047] Zone 7 (Z3 ATZ) (Z2 ATZ) (Z7) (Z7) ____/____/____ (000 to 255) x 10ms Hardwire Zone 7 Speed
[048] Zone 8 (Z4 ATZ) (Z3 ATZ) (Z8) (Z8) ____/____/____ (000 to 255) x 10ms Hardwire Zone 8 Speed
[049] Zone 9 (Z4 ATZ) (Z1 ATZ) (Z9) ____/____/____ (000 to 255) x 10ms Hardwire Zone 9 Speed
[050] Zone 10 (Z5 ATZ) (Z2 ATZ) (Z10) ____/____/____ (000 to 255) x 10ms Hardwire Zone 10 Speed
[051] Zone 11 (Z3 ATZ) (Z11) ____/____/____ (000 to 255) x 10ms Hardwire Zone 11 Speed
[052] Zone 12 (Z4 ATZ) (Z12) ____/____/____ (000 to 255) x 10ms Hardwire Zone 12 Speed
[053] Zone 13 (Z5 ATZ) (Z13) ____/____/____ (000 to 255) x 10ms Hardwire Zone 13 Speed
[054] Zone 14 (Z6 ATZ) (Z14) ____/____/____ (000 to 255) x 10ms Hardwire Zone 14 Speed
[055] Zone 15 (Z7 ATZ) (Z15) ____/____/____ (000 to 255) x 10ms Hardwire Zone 15 Speed
[056] Zone 16 (Z8 ATZ) (Z16) ____/____/____ (000 to 255) x 10ms Hardwire Zone 16 Speed
* SP7000: For zones 17-32 (ATZ), the zone timer is set at 0.6 seconds.
[6] [7] RF Zone Supervision Options (except SP4000) Keypad / Bus Module Supervision Options
OFF OFF Disabled Disabled
OFF ON Trouble only Trouble only
ON OFF When disarmed: Trouble only
When armed: Follow zone’s alarm type
Trouble only
ON ON When disarmed: audible alarm
When armed: Follow zone’s alarm type
Trouble only
