Paradox SPECTRA SP5500

Magellan / Spectra SP 13
Zone Recognition (SP Series)
Jumper settings for the APR-ZX8: A = Panel +1, B = Panel + 9, C = Panel + 17.
If a zone is already programmed and you assign a device to the same zone, a wireless zone will overwrite a keypad/hardwire
zone, and a keypad zone will overwrite a hardwire zone.
SP5500
No ATZ
SP5500
ATZ
SP6000
No ATZ
SP6000
ATZ
SP7000
No ATZ
SP7000
ATZ
Zone 1: Panel Input 1 Panel Input 1A Panel Input 1 Panel Input 1A Panel Input 1 Panel Input 1A
Zone 2: Panel Input 2 Panel Input 2A Panel Input 2 Panel Input 2A Panel Input 2 Panel Input 2A
Zone 3: Panel Input 3 Panel Input 3A Panel Input 3 Panel Input 3A Panel Input 3 Panel Input 3A
Zone 4: Panel Input 4 Panel Input 4A Panel Input 4 Panel Input 4A Panel Input 4 Panel Input 4A
Zone 5: Panel Input 5 Panel Input 5A Panel Input 5 Panel Input 5A Panel Input 5 Panel Input 5A
Zone 6: ZX8 Panel Input 1 Panel Input 1B Panel Input 6 Panel Input 6A Panel Input 6 Panel Input 6A
Zone 7: Input 2 Panel Input 2B Panel Input 7 Panel Input 7A Panel Input 7 Panel Input 7A
Zone 8: Input 3 Panel Input 3B Panel Input 8 Panel Input 8A Panel Input 8 Panel Input 8A
Zone 9: Input 4 Panel Input 4B ZX8 A Input 1 Panel Input 1B Panel Input 9 Panel Input 9A
Zone 10: Input 5 Panel Input 5B Input 2 Panel Input 2B Panel Input 10 Panel Input 10A
Zone 11: Input 6 ZX8 A Input 1 Input 3 Panel Input 3B Panel Input 11 Panel Input 11A
Zone 12: Input 7 Input 2 Input 4 Panel Input 4B Panel Input 12 Panel Input 12A
Zone 13: Input 8 Input 3 Input 5 Panel Input 5B Panel Input 13 Panel Input 13A
Zone 14: ZX8 B Input 1 Input 4 Input 6 Panel Input 6B Panel Input 14 Panel Input 14A
Zone 15: Input 2 Input 5 Input 7 Panel Input 7B Panel Input 15 Panel Input 15A
Zone 16: Input 3 Input 6 Input 8 Panel Input 8B Panel Input 16 Panel Input 16A
Zone 17: Input 4 Input 7 ZX8 B Input 1 ZX8 A Input 1 ZX8 A Input 1 Panel Input 1B
Zone 18: Input 5 Input 8 Input 2 Input 2 Input 2 Panel Input 2B
Zone 19: Input 6 ZX8 B Input 1 Input 3 Input 3 Input 3 Panel Input 3B
Zone 20: Input 7 Input 2 Input 4 Input 4 Input 4 Panel Input 4B
Zone 21: Input 8 Input 3 Input 5 Input 5 Input 5 Panel Input 5B
Zone 22: ZX8 C Input 1 Input 4 Input 6 Input 6 Input 6 Panel Input 6B
Zone 23: Input 2 Input 5 Input 7 Input 7 Input 7 Panel Input 7B
Zone 24: Input 3 Input 6 Input 8 Input 8 Input 8 Panel Input 8B
Zone 25: Input 4 Input 7 ZX8 C Input 1 ZX8 B Input 1 ZX8 B Input 1 Panel Input 9B
Zone 26: Input 5 Input 8 Input 2 Input 2 Input 2 Panel Input 10B
Zone 27: Input 6 ZX8 C Input 1 Input 3 Input 3 Input 3 Panel Input 11B
Zone 28: Input 7 Input 2 Input 4 Input 4 Input 4 Panel Input 12B
Zone 29: Input 8 Input 3 Input 5 Input 5 Input 5 Panel Input 13B
Zone 30: N/A Input 4 Input 6 Input 6 Input 6 Panel Input 14B
Zone 31: N/A Input 5 Input 7 Input 7 Input 7 Panel Input 15B
Zone 32: N/A Input 6 Input 8 Input 8 Input 8 Panel Input 16B
