Parker 512C - Chapter 3 Installing the Converter; Mechanical Installation

3-1 Installing the Converter
512C Series Converter
Chapter 3 INSTALLING THE CONVERTER
IMPORTANT: Read Chapter 12: "Certification for the Converter" before installing this unit.
Mechanical Installation
A
C
C
B
D
E
F
G
512C
PRODUCT
OVERALL DIMENSIONS
FIXING CENTRES
SIZE
SLOT DETAIL
A
B
C
D
E
F
G
512C-04
240mm
160mm
90mm
210mm
148mm
M6
15mm
7mm
512C-08
240mm
160mm
90mm
210mm
148mm
M6
15mm
7mm
512C-16
240mm
160mm
90mm
210mm
148mm
M6
15mm
7mm
512C-32
240mm
160mm
130mm
210mm
148mm
M6
15mm
7mm
Table 3.1 Product Dimensions
