Parker 512C - Setting-Up & Commissioning; Option Switches

Operating the Converter 4-2
512C Series Converter
Setting-Up & Commissioning
Option Switches
Speed Feedback Scaling
SW1
SW2
FEEDBACK VOLTAGE
OFF
ON
10 - 25V
USE P7 TO TRIM
ON
ON
25 - 75V
MAXIMUM SPEED
OFF
OFF
75 - 125V
TO REQUIRED
ON
OFF
125 - 325V
VALUE
Table 4.1 Full speed tachogenerator/armature feedback voltage.
Example:
(a) Customer wishes to run motor at 1500rpm with a 60V/1000rpm tachogenerator.
Feedback voltage = 90V
From Table 4.1 set SW1 OFF SW2 OFF adjust P7 to give desired speed.
(b) Customer wishes to run motor at 2000rpm with 320V armature.
Feedback voltage = 320V
From Table 4.1 set SW1 ON SW2 OFF adjust P7 to give desired speed.
Note: It is necessary to set these switches for both tachogenerator and armature voltage
feedback.
Speed Feedback Source
SW3
(OFF)
Tachogenerator
Controller uses Tachogenerator Feedback
for Speed Control.
SW3
(ON)
Armature Voltage
Controller uses Armature Voltage
Feedback for Speed Control.
Zero Output Source
SW4
(OFF)
Zero Output
Zero Setpoint Output
SW4
(ON)
Zero Output
Zero Speed Output
Current Scaling
FULL LOAD CURRENT CONTROLLER OPTION
SW5
SW6
SW7
04
08
16
32
OFF
OFF
OFF
½A
1A *
2A *
4A *
ON
OFF
OFF
1A
2A *
4A *
8A *
OFF
ON
OFF
1½A
3A *
6A *
12A *
ON
ON
OFF
2A
4A *
8A *
16A *
OFF
OFF
ON
2½A
5A
10A
20A
ON
OFF
ON
3A
6A
12A
24A
OFF
ON
ON
3½A
7A
14A
28A
ON
ON
ON
4A
8A
16A
32A
Table 4.2 Current Calibration ( * see note on next page )
Example:
Customer wishes to run 14 Amp Motor.
Option 1
Using 512/16 - From table 4.2 set SW7 ON, SW6 ON, SW5 OFF Ia = 14 Amp
Option 2
Using 512/32 From table 4.2 set SW7 OFF, SW6 ON, SW5 ON - Ical = 16 Amp
Turn down I Limit (P4) to give 14 Amps
