Parker 512C - Mounting the Converter

Installing the Converter 3-2
512C Series Converter
Mounting the Converter
Before connecting AC supplies to this equipment:
 Ensure good airflow over the heatsink. Maintain clearance of 75mm above and below
controller. For safety maintain a clearance of 20mm at the sides of the controller.
 Operating temperature range does not exceed 0 to +40
0
C.
 Controller is used in a Pollution Degree 2 environment.
 Avoid vibration.
Filter Installation
L1L2PEPE
LINE
LOAD
4 Holes M 6 Ins ert
4 Holes M 6 Clearance
230mm Leads
M5 Ring Lugs
A
B
C
D
L
W
E
H
PE
L1
L2
Black
Red
Green
/Y ellow
Product
Filter
Watt
Loss
Overall Dimensions
Fixing Centres
Product Fixing
Terminal
L
W
H
E
A
B
C
D
512C-04
CO389113
18W
264
165
45
240
253
120
210
148
4mm
2
512C-08
CO389113
18W
264
165
45
240
253
120
210
148
4mm
2
512C-16
CO389113
18W
264
165
45
240
253
120
210
148
4mm
2
512C-32
CO389114
36W
264
165
70
240
253
120
210
148
6mm
2
Table 3.2 Filter Installation Information
