3-3 Installing the Converter
512C Series Converter
MOTOR
 Ensure motor is mechanically secure and mounted according to manufacturers specifications
and practice.
 Inspect brush gear, ensure commutator is in good condition and brushes are free to move in
brush box and in good condition.
 Check obstructions in motor vents to maintain cooling air path.
 Ensure motor choke (if specified) is correctly wired.
 Ensure motor is free to rotate and that pulleys and couplings are correctly aligned.
 Ensure transit damage has not occurred to motor windings or connections. Disconnect the
controller before carrying out electrical measurement e.g. insulation resistance.
512C-04
512C-08
512C-16
512C-32
Overall Width
160mm
Overall Height
240mm
Overall Depth
90mm
90mm
90mm
130mm
Weight
1.5Kg
1.5Kg
1.6Kg
2.9Kg
Airflow Clearance
75mm above and below
Mounting Centres
210mm vertical x 148mm horizontal
Control Terminals
Screw Terminals will accept 2.5mm
2
stranded wire.
Terminal Tightening Torque 0.6 Nm, 4.5 lbf-in
Field Terminals
Screw terminals will accept 4mm
2
stranded wire.
Terminal Tightening Torque 0.6 Nm, 4.5 lbf-in
Power Terminals
M5 Studs with Clamp.
Terminal Tightening Torque 2.7 Nm, 24 lbf-in
Earth Terminals
M5 Cheese Head Screw.
Terminal Tightening Torque 7.1 Nm, 63 lbf-in
Table 3.3 Motor Information
