11-1 Technical Specifications
512C Series Converter
Chapter 11 TECHNICAL SPECIFICATIONS
Environmental Requirements
Enclosure
Chassis Mounting IP00.
Operating Temperature
0 to +40
o
C. (Derate 1.5%/Degree above 40
o
C)
Humidity
85% R.H. at 40
o
C. (non condensing)
Altitude
Above 1000m derate at 1% / 100m to a
maximum of 2000m
Storage Temperature
-25
o
C to +55
o
C
Transport Temperature
-25
o
C to +70
o
C
Climatic Conditions
Class 3k3, as defined by EN50178 (1998)
Operating Conditions
Installation Category
Overvoltage Category III
Pollution
Pollution Degree 2.
Maximum Supply Voltages
(Derived from a 3-phase
480Vac L - L Non earth referenced (IT)
or earth referenced (TN)
supply)
480Vac L - N Earth referenced (TN)
Wiring
 Control Cabling 0.75sq.mm minimum.
 Power cable to be minimum 600V AC rated at 1.5 x armature current.
 High speed semi-conductor fuses of the correct rating are recommended controller semi-
conductor protection, as the 512C is not internally fused. The suitability of the semi-
conductor fuse branch protection should be decided by the installer.
 Ensure a protective earth connection is made compatible with the rating.
 Isolated control wiring should not be run close to the power cabling. If screened cables are
used (recommended on setpoints and tachogenerators) connect screens to earth only at
controller end.
 Parker Hannifin Manufacturing Limited can supply fuse assemblies which can be bulkhead
mounted and also act as convenient supply isolators.
