Technical Specifications 11-2
512C Series Converter
Function
Rating
Cable Size
Fuse Isolator Kit
Fuse Rating
Parker Part
No.
512C-04
Supply
6A
1.5mm
2
/16AWG
LA057605U012
12A fuse
CH390123
Motor
4A
1.5mm
2
/16AWG
Ground
1.5mm
2
/16AWG
512C-08
Supply
12A
2.5mm
2
/14AWG
LA057605U016
16A fuse
CH390163
Motor
8A
2.5mm
2
/14AWG
Ground
2.5mm
2
/14AWG
512C-16
Supply
24A
6mm
2
/10AWG
LA057605U032
32A fuse
CH390323
Motor
16A
6mm
2
/10AWG
Ground
6mm
2
/10AWG
512C-32
Supply
48A
16mm
2
/6AWG
LA057605U050
50A fuse
CH390054
Motor
32A
16mm
2
/6AWG
Ground
16mm
2
/6AWG
ALL
Field
3A
1.5mm
2
/16AWG
LA054664
10A
CH230014
Table 11.1 Recommended Cable Sizes.
Note: The cable sizes shown are based on a Form Factor of 1.5 and an overload allowance of
110% (giving a multiplier of 1.65), they are selected for the notional rating of each
controller. Smaller cable may be used if the controller is calibrated at a lower current
level.
Terminal Tightening Torques
Control & Field
0.6 Nm
0.4 lbf-ft
4.5 lbf-in
Power
2.7 Nm
2 lbf-ft
24 lbf-in
Earth
7.1 Nm
5.25 lbf-ft
63 lbf-in
