1-4 Product Overview
514C Product Manual
Electrical Ratings
INPUT RATINGS
SYMBOL
514C-04
514C-08
514C-16
514C-32
Supply Voltage
Vs
110 - 480 Vac  10%
Maximum Supply
Voltage (Derived from
480Vac L - L Non earth referenced (IT)
or earth referenced (TN)
Three Phase Supply)
480Vac L - N Earth referenced (TN)
Supply Current
Is
6A
12A
24A
48A
Supply Frequency
fs
50/60 Hz ñ 5 Hz
Auxiliary Supply
Vaux
110/120 or 220/240 Vac ±10%
Aux. Supply Current
Iaux
3A (Includes Contactor Coil Current)
Contactor Coil
Current
3A Maximum
Installation Category
Overvoltage Category III
Earth Leakage
Without Filter - 5mA
(1)
Current at 480Vac
With Filter - 50mA
OUTPUT RATINGS
Nominal Armature
Voltage
Va
90 Vdc at 110/120 Vac
180 Vdc at 220/240 Vac
320 Vdc at 380/415 Vac
Maximum Armature
Current
Ia
4A dc 10%
8A dc 10%
16A dc 10%
32A dc 10%
Armature Current
Calibration 100%
Ical
0.1 to 4A
in 0.1A steps
0.1 to 8A
in 0.1A steps
0.1 to 16A
in 0.1A
steps
0.1 to 32A
in 0.1A steps
Nominal Motor Power
Pm
1.125kW
2.25 kW
4.5 kW
9 kW
at 320 Vdc Armature
HP
1
1
/
2
HP
3 HP
6 HP
12 HP
Overload
150% for 60 seconds
Field Current
If
3 A dc
Field Voltage
Vf
0.9 X Supply Voltage (Vs)
Maximum Armature
Form Factor
1.5
Thyristor I
2
t
300 A
2
s
Typical Controller
Dissipation at Ia 100%
15W
(2)
25W
(2)
50W
(2)
75W
(2)
UL Listed Rating @
180V dc
HP
1
/
2
HP
1 HP
3 HP
5 HP
Notes:- (1) Permanent earthing mandatory.
(2) See page 3-2 for filter watt loss information.
