Parker 514C-04 User Manual

Product Overview1-5
514C Product Manual
Mechanical
514C-04
514C-08
514C-16
514C-32
Overall Width
160mm
Overall Height
240mm
Overall Depth
90mm
90mm
130mm
130mm
Weight
1.6Kg
1.6Kg
3.0Kg
3.0Kg
Airflow Clearance
75mm Above and Below
Mounting Centres
210mm Vertical x 148mm Horizontal
Control Terminals -
1 to 24
Screw Terminals will accept 2.5mm
2
stranded wire.
Terminal Tightening Torque 0.45 Nm, 4.0 lbf-in.
Auxiliary Supply
Terminals - A1 to A4
Screw Terminals will accept 4mm
2
stranded wire.
Terminal Tightening Torque 0.5 Nm, 4.5 lbf-in.
Field Terminals - FL1,
FL2, F-, F+
Screw Terminals will accept 4mm
2
stranded wire.
Terminal Tightening Torque 0.5 Nm, 4.5 lbf-in.
Power Terminals -
L2/N, L1, A+, A-
M5 Studs with Clamp.
Terminal Tightening Torque 2.7 Nm, 24 lbf-in.
Earth (Grounding)
Terminals
M5 Cheese Head Screw.
Terminal Tightening Torque 7.1 Nm, 63 lbf-in.
ENVIRONMENTAL REQUIREMENTS
Enclosure
Chassis Mounting IP00 (UL open-type)
Operating Temperature
0 to +40
o
C. (Derate 1.5%/Degree above 40
o
C).
Humidity
85% R.H. at 40
o
C. (Non-condensing).
Altitude
Above 1000m derate at 1% / 100m to a maximum of
2000m.
Storage Temperature
-25
o
C to +55
o
C.
Pollution
Pollution Degree 2.
Transport Temperature
-25
o
C to +70
o
C.
Overvoltage
III
