Parker 514C-04 User Manual

2-2 Pre-Installation Planning
514C Product Manual
TERMINAL DESCRIPTIONS
Control Terminals
TERMINAL
FUNCTION
DESCRIPTION
NOTES
T1
Tacho Feedback
Motor Mounted Tachogenerator Input.
Proportional to Motor Speed.
+350 Vdc Max. Approx
220 kohm.
T2
Not Connected
T3
Speed Meter Output
Analogue Output,
0 to 10V for 0 to 100% Speed.
5mA output
S/C protected
T4
DO NOT USE
Pending Change.
T5
Run Input
Digital Input to Run Controller.
+24V to Run.
0V to Stop.
T6
Current Meter
Output
Analogue Output, 0 to +7.5V =
150% Calibrated Current
SW1/5 Off = Bipolar
SW1/5 On = Magnitude
5mA output
S/C protected
T7
Torque/Current
Limit Input
Analogue Input,
0 to +7.5V = 0 to 150% of Calibrated
Current.
approx.
100 kohm
T8
0V Common
Analogue / Digital Signal Common
T9
Setpoint Ramp
Output
Analogue Output,
0 to 10V = 0 to 100% Ramped
Setpoint.
5mA output
S/C protected
T10
Positive Trim Speed
Setpoint Input
Analogue Input,
0 to 10V = 0 to 100% Speed.
approx.
100 kohm
T11
0V Common
Analogue / Digital Signal Common.
T12
Total Setpoint Sum
Output
Analogue Output,
0 to 10V = 0 to 100% Speed.
5mA output
S/C protected
T13
Setpoint Ramp Input
Analogue Input,
0 to +10V = 0 to 100% Forward
Speed.
0 to -10V = 0 to 100% Reverse Speed.
approx.
100 kohm
T14
+10V Reference
Output
Analogue Output,
+10V Reference for Speed/ Current
Setpoints.
5mA output
S/C protected
T15
Stall Override Input
Digital Input to Override Stall Detection
+10V = Override.
approx.
100 kohm
T16
-10V Reference
Output
Analogue Output,
-10V Reference for Speed/ Current
Setpoints.
5mA output
S/C protected
T17
Negative Trim
Speed Setpoint
Input
Analogue Input,
0 to +10V = 0 to 100% Reverse Speed
0 to -10V = 0 to 100% Forward Speed.
approx.
100 kohm
