D-81

Programming

890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D

MOTOR INDUCTION

SETUP::MOTOR CONTROL::MOTOR INDUCTION

Designed for all Motor Control Mode, except PMAC Control Mode.

In this function block you enter the details of the motor under control and any available motor nameplate information.

The Autotune feature will determine the MAG CURRENT, STATOR RES, LEAKAGE INDUC, MUTUAL INDUC and ROTOR

TIME CONST motor model parameter.

The OVERLOAD parameter determines the allowed level of motor overload. This can be especially useful when operating

with motors smaller than the drive rating.

Note Do not attempt to control motors whose rated current is less than 25% of the drive rated current. Poor motor control

or Autotune problems may occur if you do.

Parameter Descriptions

POWER

PREF: 27.02

Default: 1.5 kW

Range: 0.00 to 3000.00kW

This parameter contains the motor nameplate power.

* BASE FREQUENCY

PREF: 27.03

Default: 50.0 Hz

Range: 7.5 to 1000.0Hz

This parameter contains the motor nameplate base frequency. Refer to FLUXING, page D-54.

* MOTOR VOLTAGE

PREF: 27.04

Default: 230.0 V

Range:

0.0 to 575.0V

This parameter contains the motor nameplate voltage at base frequency.

MOTOR CURRENT

PREF: 27.05

Default: 6.26 A

Range: 0.00 to 3276.70 A

This parameter contains the motor nameplate full-load line current.

MAG CURRENT

PREF: 27.06

Default: 2.50 A

Range: 0.00 to 3276.70 A

This parameter contains the motor model no-load line current as determined by the auto-tune.
