7.2 Handling - Operating space
ICEP080E-ICEP120E
Handling Operating space
A = 1600 mm
B  4000 mm
C 7000 mm
D = 1200 mm
E
D
1500mm
1500mm
1500mm
1500mm
2000mm
D
B
C
E = 900 mm
A
1
0
9
0
900
