Variable modbus
ICEP080E-ICEP120E
MODBUS
&)
unit adress

1
Default
Parametr
&)
BaudRate

9600
&)
Protocol Parity

1
&)
EVEN

NONE

ODD

Not configurable
Stop Bit

Data Bit

Address with offset 40000 (es: 8964+40000=48964)
Address Display label App
type
Default Min Max Unit Read Only Note
8964 Set INT 13(55,4) LIS 65(149) °C/(°F) Read&write Set point
8965 dIF1 INT 4(7,2) 0,3(0,5) 10(18) °C/(°F) Read&write Differential 1 for thermostating
8966 dIF2 INT 0,3(0,5) 0,3(0,5) 10(18) °C/(°F) Read&write Differential 2 for thermostating
8969 OFFC INT 2(3,6) ONC 10(18) °C/(°F) Read&write Differential for compressor OFF
8970 ONC INT 1(1,8) 0(0) OFFC °C/(°F) Read&write Dirrerential for compressor ON
8973 LiS INT 5(41) LA2 65(149) °C/(°F) Read&write Set point lower limit
8974 HA1 INT 60(140) -40(-40) 65(149) °C/(°F) Read&write B1 High terperature alarm
8975 LA1 INT -40(-40) -40(-40) 65(149) °C/(°F) Read&write B1 Low temperature alarm
8976 db1 INT 1(1,8) 1(1,8) 10(18) °C/(°F) Read&write B1 Low level temperature alarm retrigger
8977 HA2 INT 60(140) -40(-40) 65(149) °C/(°F) Read&write B2 High temperature alarm
8978 LA2 INT 2,5(36,5) -40(-40) 65(149) °C/(°F) Read&write B2 Low temperature alarm
8979 dI2 INT 4(7,2) 1(1,8) 10(18) °C/(°F) Read&write B2 Alarm differential
8980 HA3 INT 60(140) -40(-40) 65(149) °C/(°F) Read&write B3High temperature alarm
8981 LA3 INT -30(-22) -30(-22) 65(149) °C/(°F) Read&write B3 Low temperature alarm
8982 SEA INT 19(66,2) LIS 65(149) °C/(°F) Read&write Set point (B1) antifreeze
8983 dIA INT 1(1,8) 1(1,8) 10(18) °C/(°F) Read&write Thermostating differential (B1)
8984 ArA INT 5(41) -30(-22) 65(149) °C/(°F) Read&write Set point activation (B3)
8985 DtHA INT 5(9) 0(0) 30(54) °C/(°F) Read&write Differential for dipendent water exit regulation
8986 SRQH INT 30(86) -10(14) 55(131) °C/(°F) Read&write SetH point for control panel heater
8987 drq INT 19(34,2) 0(0) 30(54) °C/(°F) Read&write Differential control panel heater
8988 SrC INT 15(59) -30(-22) 50(122) °C/(°F) Read&write Setpoint Carter Heater
8989 drC INT 2(36) 0(0) 10(18) °C/(°F) Read&write Differential value for carter heater
8990 SRQL INT 5(41) -10(14) 30(86) °C/(°F) Read&write SetL point for control panel resistor
8995 PStA INT 0 0 1 Read Only Status ON/OFF dryer
8996 ON_OFF_SUP BOOL FALSE FALSE TRUE Read&write Supervisor ON OFF request (to change the state machine - change True from "0" to "1")
16385 rE USINT 0 0 2 Read&write Remote ON/OFF enable
16387 SUP BOOL FALSE(0) FALSE(0) TRUE(1) Read&write ON/OFF enable from supervison
16384 C-F BOOL FALSE(0) FALSE(0) TRUE(1) Read&write Unit of measure (FALSE=°C, TRUE=°F)
16386 rAL USINT 0 0 2 Read&write Alarm relè management
16388 Ud4E BOOL FALSE(0) FALSE(0) TRUE(1) Read&write Enable antifreeze resistor 0=disabled
16390 ASt BOOL TRUE(1) FALSE(0) TRUE(1) Read&write Autostart enable 0=NO 1=YES
16391 r0n UINT 6 0 300 sec Read&write Main power supply return
16465 CPT BOOL FALSE(0) FALSE(0) TRUE(1) Read&write CPT control 1=Enable
16445 Erd BOOL FALSE(0) FALSE(0) TRUE(1) Read&write Enable managing water with Ambient temperature
8999 Dma INT 25(77) 0(32) 37(98,6) °C/(°F) Read&write Max value to stop compressor in ERD
8961 dMin INT 15(59) -20(-40) 37(98,6) °C/(°F) Read&write Min value to run compressor in ERD
16423 dAS USINT 5 0 10 Minutes Read&write Minimun time between two switch ON of the same compressor (minutes)
16431 tH1 INT 0 0 9999 KHours Read&write Compressor 1 working hours warning threshold (x1000)
16472 tH1L INT 0 0 9999 Hours Read&write Compressor 1 working hours warning threshold
16409 CHA1 BOOL TRUE(1) FALSE(0) TRUE(1) Read&write HA1 alarm management
16414 CHA2 BOOL TRUE(1) FALSE(0) TRUE(1) Read&write HA2 alarm management 0=Warning; 1=Alarm; 2=System
16411 CLA1 BOOL FALSE(0) FALSE(0) TRUE(1) Read&write LA1 alarm management
16419 rLa USINT 5 0 15 n° Read&write Max number of Events LA2 Alarm
16420 tLa USINT 60 5 60 Minutes Read&write Interval Time LA2 Alarm
