7.6 Spare parts
ICEP080E-ICEP120E
Component (7.7-7.8-7.9)
ICEP080E ICEP100E ICEP120E
Electrical kit W - 398H473807
Compressor kit W
1 4
KM1
398H473769 398H473624 398H473625
Fan kit W
3
ET-398H381859
Expansion valve kit W
4 5
398H473813 398H473814
Plate type heat exchanger kit W
6
398H473648
Pump kit P30 (3 barg)
W
7
398H473621
Pump kit P15 (1.5 barg)
398H473622
Pump kit P50 (5 barg) 398H473623
Tank kit W
8
398H473651
Refrigerant condenser W
2
ET-398H114855 ET-398H114856
Refrigerant filter W
4
398H206224 398H206225
Water manometer W
11
398H354031
Water outlet temperature sensor W
13
398H275894
Evaporator temperature sensor (anti-freeze) W
14
398H275894
Water level sensor W
15
398H275924
Electronic control W
A1
16
398H473649
Differential water pressure switch W
17
398H354136
High pressure switch W
18
ET-398H474520
Low pressure switch W
19
ET-398H474521
Refrigerant suction manometer W
20
398H354042
Refrigerant discharge manometer W
21
398H354042
