Appendix C : hardware characteristics
Digital Inputs
input impedance 7k ohm
VH 15..30 V
VL 0..3 V
Digital outputs
type PNP open collector
VH 20..26 V
Io for a single output 100 mA
maximum total current 500 mA
maximum voltage-free contact voltage
(outputs 6A and 6B)
110 V~
maximum voltage-free contact current
(outputs 6A and 6B)
600 mA
analog reference
type differential
impedance 20k ohm
range ± 10 V
CMMR > 60 dB
resolution 15 bits
auxiliary analog input
type differential
impedance 250k ohm
range ± 10 V
CMMR > 40 dB
resolution 10 bits
analog output
type single ended
Io max. 1.5 mA
range ± 10 V
resolution 8 bits
