Parker P1/PD Series User Manual

Parker Hannin Corporation
Hydraulic Pump and Power Systems Division
Marysville, Ohio USA
Bulletin HY28-2708-02/SVC/EN | July 2019
Medium Pressure Axial Piston Pumps
P1/PD B-mod Service Information
48
Pump Model Part Number A B C D E F
018
(“01”, “02”, “04”
Shafts)
3.00 in
(76.20 mm)
2.00 in
(50.80 mm)
0.75 in
(19.05 mm)
15°
1.135 in
(28.82 mm)
0.805 in
(20.45 mm)
018
(“06” Shaft)
3.00 in
(76.20 mm)
2.00 in
(50.80 mm)
0.75 in
(19.05 mm)
15°
1.135 in
(28.82 mm)
0.66 in
(16.76 mm)
028 / 045
( “01”, “02”, “04”
Shafts)
3.00 in
(76.20 mm)
2.00 in
(50.80 mm)
0.75 in
(19.05 mm)
15°
1.50 in
(38.10 mm)
1.024 in
(26.00 mm)
018 / 028 / 045
(“08” Shaft)
3.00 in
(76.20 mm)
2.00 in
(50.80 mm)
0.75 in
(19.05 mm)
15°
1.135 in
(28.82 mm)
0.885 in
(22.50 mm)
060 / 075 / 085 213-0-004195
4.25 in
(108 mm)
2.25 in
(57.1 mm)
1.00 in
(25.4 mm)
10°
1.373 in
(34.90 mm)
0.885 in
(31.75 mm)
100 SAE 213-0-004206
4.25 in
(108 mm)
2.78 in
(70.6 mm)
1.00 in
(25.4 mm)
10°
1.703 in
(43.26 mm)
1.5 in
(38.1 mm)
100 ISO 213-0-004207
4.50 in
(114 mm)
3.00 in
(76.2 mm)
0.88 in
(22.4 mm)
15°
1.703 in
(43.26 mm)
1.577 in
(40.06 mm)
140 SAE 213-0-004200
4.25 in
(108 mm)
2.78 in
(70.6 mm)
1.00 in
(25.4 mm)
10°
2.088 in
(53.04 mm)
1.751 in
(44.48 mm)
140 ISO 213-0-004201
4.50 in
(114 mm)
3.00 in
(76.2 mm)
0.88 in
(22.4 mm)
15°
2.088 in
(53.04 mm)
1.970 in
(50.04 mm)
T5 Rear Bushing Installation Tool
(18 thru 45)
Pump Size A B
018
0.146 in
(3.71 mm)
0.772 in
(19.9 mm)
028
0.157 in
(4.00 mm)
0.85 in
(21.6 mm)
045
0.157 in
(4.00 mm)
0.95 in
(24.1 mm)
A
B
102 mm
(4.0 in)
25 mm
(1.0 in)
13 mm
(.5 in)
38 mm
(1.5 in)
38 mm
(1.5 in)
29 mm
(1.14 in)
T3 Seal Guard
+0.05 / -0.00mm
(+0.002 / - 0.000 in)
A
B
+/- 0.05mm
(+/- 0.002 in)
D
C
BLEND RADIUS
& POLISH O.D.
30˚
F
DIA BORE
E
DIA.
Assembly Tools
