HMI (Human Machine Interface)
external buzzer, low-side output 1 or 2 can drive either a steady state low or a
PWM output to drive a buzzer. This low-side output is also capable of sinking
500mA.
7.5. Video
The PHD50 and PHD70 support analog video cameras.
▪ PHD50 has 1 video input
▪ PHD70 has 2 video inputs
The PHD50 supports one D1 resolution PAL/NTSC input.
The PHD70 supports dual D1 resolution PAL/NTSC inputs and can display both
video feeds simultaneously.
7.5.1. Video Input Capabilities
The following table provides specifications for the video inputs:
Video Input Specifications
Item
Min
Nom
Max
Unit
Input voltage range
-5.6
5.6
V
Input resistance
75

Capacitance at pin
65
100
pF
