5
About the PHD (Parker Hannifin Display)
1.1. Diagram conventions
The following symbols are used in the schematic diagrams in this document:
Symbol
Meaning
General input
General output
Frequency input
Analog input
Frequency sensor
Pulse sensor
Resistive sensor
General sensor
Application switch
Load
Pull-down resistor
