Parker PHD Series User Manual

4 PHD
About the PHD (Parker Hannifin Display)
PHD70
Characteristic
Description
Display
Viewing angle
Brightness
Contrast ratio
Readable with polarized glasses
7.0" 800 x 480 IPS LCD, PCAP touchscreen
Aspect ratio 16:9
Theta X +80° / -80°, Theta Y +80° / -80°
430 cd/m²
600:1
yes (landscape and portrait orientation)
Processor
Freescale iMX6Solo/Dual/Quad
Flash 1 GB
RAM 512 MB DDR3
Communication
CAN x 2
USB Host/Device x 1 (default is Device)
Inputs
10 General Purpose Inputs;
2 - Frequency Inputs (for rotary encoder)
8 - Digital (active-high/low) or
8-10 GPIO for Keypad Interface
Ambient Light Sensor
2 simultaneous Video Inputs (NTSC, PAL)
Outputs
2 x low-side 500mA
1 x 5Vdc sensor supply 500mA
1 x 12Vdc sensor supply 500mA
up to 10 high-side, 4.3V @ 5mA
Wake-up sources
Power, CAN1, CAN2, Touch Screen, External Keypad
(GPIO), Encoder
Connector
2 x Molex MX150, 20 pin
