About the PHD (Parker Hannifin Display)
PHD50
Characteristic
Description
Display
Viewing angle
Brightness
Contrast ratio
Readable with polarized glasses
5.0" 800 x 480 TN LCD, PCAP touchscreen
Aspect ratio 16:9
Theta X +80° / -80°, Theta Y +80° / -80°
380 cd/m²
500:1
yes (landscape and portrait orientation)
Processor
Vybrid VF5xxR (Cortex-A5 core)
Flash 32 MB
RAM 128 MB DDR
Communication
CAN x 1
USB Host/Device x 1 (default is Device)
Inputs
10 General Purpose Inputs;
2 - Frequency Inputs (for rotary encoder)
8 -Analog or
8-10 GPIO for Keypad Interface
Ambient Light Sensor
1 Video inputs (NTSC, PAL)
Outputs
2 x low-side 500mA
1 x 5Vdc sensor supply 500mA
1 x 12Vdc sensor supply 500mA
up to 10 high-side, 4.3V @ 5mA
Wake-up sources
Power, CAN, Touch Screen, External Keypad (GPIO),
Encoder
Heater for cold applications
High wattage resistors (built-in)
Connector
2 x Molex MX150, 20 pin
