1. throttle cable stop screw
1
Electric start type
1. Turn the gear shift lever to neutral position.
2. Check if the arresting stop on the throttle accelerograph enforce touches the check plate on the
bracket.
2
1
1. check plate 2. arresting stop
3. Loosen the lock nut and take out the cotter pin, then remove the cable joint.
1. cotter pin 2. cable joint 3. lock nut
2
1
3
4. Adjust the joint position to make the joint hole align with the pin on the throttle accelerograph
enforce.
CAUTION:
The cable joint must be screwed in for over 8mm.
5. Fit on the cotter pin and tighten the lock nut.
Idling speed
Check idling speed, and adjust it if necessary.
1. Preheat engine for 5 minutes.
2. Attach the tachometer to the spark plug wire to measure idling speed RPM. If out of
specification, adjust it.
Idling speed: 900~1000 r/min
18
