DISASSEMBLING
1. Open the top cowling.
2. Screw loosely the adjusting nut of the arrester tightwire.
1
1. Adjusting nut
3. Remove the tightwire from the arrester.
4. Remove the starter fixing bolts, and remove the starter.
STARTER ROPE REPLACEMENT
1. Pull the starter rope out, and insert it in the notch of the start-up wheel. Turn the start-up clockwise
until the volute spring is free.
2. Pull the starter rope out completely.
3. Remove the starter handle cover from the starter handle, and remove the starter rope.
Untie the knot at the end of the starter rope.
4. Pull out the starter rope from the start-up wheel completely.
5. Insert the new starter rope into the starter，and fix the starter rope onto the start-up wheel and starter
handle. At the end of the rope tie a knot as shown.
27
