Parsun F15BW Service Manual

POWER UNIT
NOTICE
To avoid accidental start of outboard engine during maintenance, please take enough safety measures to
disconnect the ignition system. For instance, remove the engine stop lanyard from engine stop switch
assembly, and remove spark plug cap from spark plug.
EXPLOSIVE DRAWING
DESCRIPTION
PART NO.
REMARKS
54 Nm
WASHER 6
BOLT M6x35
OIL PUMP ASSY
MAT,QIRPROOF
CAMSHAFT ASSY
OIL SEAL 18X35X7-R
WASHER
BELT PULLEY,DRIVEN
BIG WASHER 6
BOLT M6x16
RING RUBBER A
COVER,DUST
BELT,TIMING
NUT
WASHER
BELT PULLEY,TIMING
RUBBER RING B
KEY,WOODRUFF
特大垫圈6
六角螺栓M6x16
平垫圈6
3
1
1
1
2
1
1
1
1
1
1
1
1
2
4
1
3
1
凸轮轴组件
机油泵密封垫
皮带罩壳
正时皮带
正时带轮螺母
带轮罩橡胶圈 B
正时带轮
从动带轮
带轮罩橡胶圈 A
从动齿轮垫圈
油封 18X35X7-R
正时带轮盖板
六角螺栓M6x35
机油泵总成
正时带轮半圆键
F15-07040200
F15-07040016
F15-07040017
F15-07040018
GB/T5287-6
GB/T5783-M6x16
F15-07050003
F15-07030004
F15-07030005
F15-07010027
F15-07030003
GB/T1099-1979
F15-07000002
F15-07000024
F15-07040008
GB/T5783-M6x35
GB/T97.1-6
F15-07040500
O
O
M6x20 mm
13 Nm
M6x35 mm
8 Nm
46
