WIRING DIAGRAM
7
6
W
9
Y/R
8
Y/R
Y
Y
B
W
W
B
B
R/W
B
8
5
3
Br
L
L
B
r
Y
O
B
B
O
Y
10
4
2
G
G
G
L
L
L
L
L
B
R
B
1
B
R/W
○
1 C D I
○
4 Oil press switch
○
7 Engine stop switch
○
10 Spark plug
○
2 Lighting coil
○
5 Pulsed coil
○
8 Grounding wire
○
3 Charge coil
○
6 Ignition coil
○
9 Oil alert light
Wire beam color:
W White O Orange Y/R Yellow/Red
B Black L Blue R/W Red/White
R Red G Green
Y Yellow Br Brown
SPARK PLUG IGNITION
1. Remove spark plug cap from spark plug.
2. Connect the ignition tester to the spark plug cap.
3. Start the engine, and observe the sparks through the discharge window of the tester.
WARNING:
Do not touch any joint part of the lead wire of the tester. Keep away from inflammable gas or
liquid, to prevent accident resulting from spark ignition.
