1
1. Oil level plug
3. CHECK STEERING SYSTEM
Check if steering is stable.
Check if steering friction is adjusted correctly.
Turn clamp handle screw clockwise to increase
resistance.
Turn clamp handle screw counter clockwise to lower
resistance.
1. Clamp handle screw
4. CHECK SHIFT LEVER AND THROTTLE
Check if the shift lever is operated smoothly.
Check if the throttle grip is turned smoothly from full closed position to full open position.
5. CHECK ENGINE STOP SWITCH ASSY
Check if the engine stops when pushing the engine stop switch assembly or pulling out the
stopper hang rope.
6. CHECK COOLING WATER CHECKING HOLE
When the engine is running, check if
cooling water overflows at the cooling
water checking hole.
1
1. Cooling water checking hole
7. BREAKING-IN RUNNING
○
1 Initial 1 hour: operate the engine at 2000 r/min or about a half throttle.
② The second hour: operate the engine at 3000 r/min or about 3/4 throttle.
③ The following 8 hours: operate the engine at full throttle continuously. Each operation
time doesn’t exceed 5 minutes.
8. INSPECTION AFTER BREAKING-IN RUNNING
○
1 Check if gear oil contains water.
② Check if the fuel line leaks.
③ After breaking-in running, operate the engine at idling speed. Use cleaning tool to wash
5
