6. Insert the start rope in the notch of the sheave drum and turn the sheave drum several rounds in
counter clockwise direction.
7. Pull the starter handle many times to check if the sheave drum rotates stably. If necessary, repeat
step 6 and step 7.
DISASSEMBLING AND INSPECTION
1. Remove the start rope.
2. Remove starter bolt, and remove press plate.
3. Remove the sheave drum
WARNING
Uninstall the sheave drum carefully, to ensure that the volute spring does not pop out to hurt
people.
4. Remove the volute spring.
5. Remove the detent and detent wrest spring.
6. Inspect if the detent is cracked, worn or damaged. If necessary, replace it.
7. Check if the drive pawl is cracked, worn or damaged. If necessary, replace it.
8. Inspect if the drive spring is broken, cranked or damaged. If necessary, replace it.
9. Check if the volute spring is broken, cranked or damaged. If necessary, replace it.
25
