5. Inspect the fuel tank and fuel tank cover for crack, leakage or damage.
Replace if necessary.
6. Inspect the tank strainer for dirt or clog. Clean or replace if necessary.
OIL SWITCH REMOVAL AND INSPECTION
1. Remove the fuel tank.
2. Remove the bolts fixing the thumb wheel of the oil switch, and remove the thumb
wheel.
2
1
3
4
1. Oil switch 2. Thumb wheel 3. Plus pan head screw M4X12 4. Thumb wheel block
3. Remove the bolts fixing the oil switch, and remove oil switch.
1. Screw 2. Gasket 3. Oil switch 4. Bottom cowling
4. Inspect the oil switch for leakage under prescribed pressure, replace if necessary.
Prescribed air pressure: 0.1Mpa
FUEL JOINT REMOVAL AND INSPECTION
1. Remove the bolts fixing the fuel joint.
2. Remove the fuel joint.
37
