DISASSEMBLING
1. Open the top cowling
2. Screw loosely the adjusting nut of the dent tightwire.
1
1. Adjusting nut
3. Remove the tightwire from the detent.
4. Remove the starter fixing bolt, and remove the starter.
STARTER ROPE REPLACEMENT
1. Pull the starter rope out, and insert it in the notch of the sheave drum. Turn the sheave drum
clockwise until the volute spring is free.
2. Pull the starter rope completely.
3. Remove the starter handle cover from the starter handle, and remove the starter rope.
Untie the knot at the end of the starter rope.
4. Pull out the starter rope completely.
5. Insert the new starter rope into the starter assembly, and fix the
rope onto the sheave drum and starter handle.
At the end of the rope tie a knot as shown.
24
