PAGE 33
TABLE 3-3 TUNE MODE CONFIGURATION PROCEDURE
Depress the SCROLL key until tunE is displayed. Use the DOWN key to enter the Tune
mode. Depress and release the SCROLL key to sequence through the parameters and their
values. Use the UP and DOWN keys to adjust the values. After adjusting a
parameter, depress the SCROLL key to proceed to the next parameter. After all
selections have been made, depress the UP key with a parameter code displayed (not a
setting) to exit the mode.
Note: The Program, Tune and Enable Mode selections can be conveniently recorded on
the Software Reference Sheet located in Appendix E (page 70).
STEP DESCRIPTION DISPLAY AVAILABLE FACTORY YOUR
CODE SETTINGS SETTING SETTING
1 Spread (Second SPrd -1000 to 1000 °/units
0
Output Position)
2 Process Alarm PAL -9999 to 9999 °/units
0
3 Deviation Alarm dAL -3000 to 3000 °/units
0
4 Deviation Band dbAL 1 to 3000 °/units
1
Alarm
5 1st Output Pb1 1 to 3000 °/units
100
Proportional
Band Width
6 2nd Output Pb2 1 to 3000 °/units
100
Proportional
Band Width
7 Manual Reset rSEt -1500 to 1500 °/units
0
8 Automatic Reset ArSt 0.0 to 100.0 repeats
0.0
(Integral) per minute
9 Rate ( Derivative) rAtE 0.0 to 10.0 minutes
0.0
10 Cycle Time Ct1 1 to 240 seconds
30
Output 1
11 Cycle Time Ct2 1 to 240 seconds
30
Output 2
12 Position Prop. SEnS 0.0 to 50.0 %
1.0
Sensitivity
13 First Output FoP -1000 to 1000 °/units
0
Position
To Next Page
