Partlow MIC 2000 User Manual

PAGE 70
InPs
ICor
out1
o1PL
out2
o2PL
out3
rLyA
rLyb
rLyC
diSP
dPoS
Euu
EuL
HySt
rSP
rSPu
rSPL
SPL
SPuL
SPLL
AtFr
PFF
dFF
FScn
Prnd
Co1r
Co2r
Pout
Pou
PoL
PorA
POAP
SPrr
CCon
CbS
CAd
ENAB ON OFF
EtSt
ECAL
EPro
Etun
ESby
ESPS
ESPC
SPrd
PAL
dAL
dbAL
Pb1
Pb2
rSEt
ArSt
rAtE
Ct1
Ct2
SEnS
FoP
Comm
EB
Appendix E
Software Record/Reference Sheet
EA
EA
Program Mode
Continued
Tune Mode
Enable ModeProgram Mode

Partlow MIC 2000 Specifications

General

Display	Dual 4-digit LED
Communication	RS-485 Modbus RTU
Input	Thermocouple, RTD, mA, V, mV
Output	Relay, SSR, mA, V
Control Modes	On/Off, PID
Power Supply	24 VAC/VDC, 100-240 VAC
Dimensions	96 x 96 mm
Enclosure Rating	IP65 front panel
Alarms	4 programmable alarms
