PAGE 67

Appendix D - Specifications

Input Specifications

THERMOCOUPLE

TYPE RANGE TYPE RANGE

J -130 TO 760C E 0 TO 750C

-200 TO 1400F 0 TO 1400F

K -130 TO 1370C B 200 TO 1800C

-200 TO 2500F 400 TO 3300F

T -200 TO 400C N 0 TO 1300C

-330 TO 750F 0 TO 2370F

R 200 TO 1650C C 200 TO 2300C

400 TO 3000F 390 TO 4170F

S 200 TO 1650C

400 TO 3000F

RTD VOLTS MILLIVOLTS

100 ohm 0 to 5 VDC 0 to 25 mVDC

(.00385 OHM/OHM/C) 1 to 5 VDC 0 to 50 mVDC

-140 to 400C 10 to 50 mVDC

-220 to 750F

MILLIAMPS REMOTE SETPOINT

* 0 to 20 mADC 0 to 5 VDC

1 to 5 VDC

* 4 to 20 mADC is accommodated via the 1-5 VDC with the

addition of a shunt resistor.

SENSOR FAULT DETECTION

Displays Hi or Lo process input for thermocouple or RTD inputs (10% above or below range)

and sensor break, SnSr. On/Off outputs and proportional outputs go off. Sensor fault

detection is not functional for 0 to 5 VDC.
