PAGE 3
Table of Contents
SECTION 1 - GENERAL Page Number
1.1 Product Description 5
SECTION 2 -
INSTALLATION & WIRING
2.1 Installation and Wiring 7
2.2 Preparation for Wiring 8
2.3 Input Connections 13
2.4 Output Connections 19
SECTION 3 -
CONFIGURATION & OPERATION
3.1 Configuration and Operation 22
3.2 Operation Summary 22
3.3 Configuration Summary 24
3.4 Tune Mode Operation 34
SECTION 4 - CONTROL CAPABILITY
4.1 Control Capability 37
4.2 Control Responses 37
4.3 Direct/Reverse Operation of Control Outputs 37
4.4 On-Off Control/Latched On-Off 38
4.5 Time Proportioning Control 38
4.6 Current Proportioning Control 38
4.7 Position Proportioning Control 38
4.8 Dual Output Control 40
4.9 Manual Operation of Proportional Outputs 41
4.10 Automatic Transfer Function 41
4.11 Setpoint Adjustments 42
SECTION 5 - SERVICE
5.1 Service 44
5.2 Calibration 44
5.3 Test Mode 48
5.4 Troubleshooting and diagnostics 52
APPENDICES
A - Board Layout - Jumper Positioning
Figure A-1 Power Supply Board 59
Figure A-2 Processor Board 60
Figure A-3 Option Board 61, 62
B - Glossary of terms 63
C - Model Number Hardware Matrix Details 66
D - Specifications 67
E - Software Record/Reference Sheet 70
Warranty Inside back cover
