Partner SP-1030 - SP-1030 Panel

57
SP-1030 Panel
1. Rotate the LCD screen forward .
2. Remove the screw that secure the
base to the SP-1030.
The screen is
fragile. Placing
the monitor
face-down
on a at, soft
area prevents
scratches,
defacing, or
breakage.
CAUTION
3. Disconnect cables from HDD.
4. Lift the panel and remove it from
the base.
