Partner SP-1030 - Mainboard Connectors; Panel Control Board Connectors; Figure 4.3 SP-1030 Mainboard Connectors; Figure 4.4 SP-1030 Panel Control Board Connectors

51
Panel control board connectors
connector to
mainboard
connector to touch
panel
connector to touch
panel
Figure 4.3 SP-1030 mainboard connectors
Figure 4.4 SP-1030 panel control board connectors
Mainboard connectors
connector to
MSR
connector to
LCD panel
connector to
LCD panel
connector to
SATA HDD
connector to
panel control
board (CN17)
connector to
12V-out port
connector to
power LED
connector to
power button
connectors
to fan
connector to
speaker
connector to
COM4 port
connector to
USB port
connector to
HDD power
connector to
audio jacks
