64 CHAPTER 5 REPLACING FIELD REPLACEABLE UNITS (FRUs)
I/O Shield
Before proceeding, remove the
following FRUs.
• “SP-1030 Panel” on page 51.
• “Panel Back Cover” on page
52.
1. Remove all screws from the
I/O ports.
2. Remove two screws from the
I/O shield.
3. Remove the I/O shield.
To Next Page
