Parweld XTM 221Di - Table of Contents

3
Contents
Page
1.0 Safety Precautions 4-5
2.0 Product Description 5
3.0 Technical Specications 6
4.0 Installation 6
4.1 Location 6
4.2 Input and Grounding Connection 7
5.0 Description of Controls 7
and Torch Connections
6.0 Operation 8-10
6.1 Use of Controls 8
6.2 Language of Operation 8
6.3 Process Selection 8
6.4 MIG Welding Preparing the Machine 9-10
7.0 Setting the Machine for Welding 10-20
7.1 MIG Torch Selection 10
7.2 MIG SYN - Synergic MIG Welding 10-11
7.3 MIG MAN - Manual MIG Welding 11
7.4 Remote Control MIG Torch 11
7.5 MIG Welding Procedure 12
7.6 MMA Welding 12
7.7 TIG Welding 12
7.7.1 TIG Torch Selection 12
7.7.2 TIG Torch Installation 13
7.7.3 TIG Welding Setup 13-15
7.7.4 TIG Welding Guide 15
7.7.5 DC TIG Welding (No Pulse) 15-16
7.7.6 AC TIG Welding (No Pulse) 16-17
7.7.7 TIG Welding (With Pulse) 17-18
7.8 Plasma Cutting 18-19
7.8.1 Setting Air Pressure 18
7.8.2 Preparing to Cut 18
7.8.3 Mesh Cutting 19
7.8.4 Normal Cutting 19
7.8.5 Gouging 19
7.8.6 Torch Operation Logic 19
7.9 Saving to Memory 20
7.10 Process Switch 20
8.0 Fault Finding 21-25
8.1 MIG Welding Problems 21-22
8.2 MMA Welding Problems 23
8.3 TIG Welding Problems 24
8.4 Plasma Cutting Problems 25
9.0 Control Torch Schematic 26-27
10.0 Accessories 28
10.1 Feed Rolls 28
10.2 MIG Torch Spares 28
10.3 Gas Equipment 28
11.0 EC Declaration of Conformity 29-30
11.1 RoHS Compliance Declaration 29
11.2 WEEE Statement 30
11.3 Statement of Warranty 30
