Parweld XTM 221Di - Input and Grounding Connection; Description of Controls and Torch Connections

1
2
www.parweld.com
7
8. Wire Spool Holder
9. Wire Feed Unit
10. Air pressure regulator
(plasma)
1. Power Switch for Incoming Mains
2. QF Incoming Gas Connection MIG
3. QF Incoming Gas Connection TIG
4. QF Incoming Air Connection Plasma
5. MIG Torch Connector
6. Work Lead Connector
7. TIG Torch / Electrode Holder Socket
9
7
6
10
8
5
11
13
12
13
5.0 Description of Controls
and Torch Connections
14
15
4.2 Input and Grounding Connection
WARNING
Before starting the installation, check that your power supply
is adequate for the voltage, amperage, phase, and frequency
specied on the Machine nameplate.
The 110/230 volt 50 Hz machine is supplied with a 3m input cable
and without plug, ensure that you connect a plug that is suitably rated
for the power draw of the machine and the environmental location.
Have a qualified electrician connect the input plug.
3
4
11. Multifunction Control Knob
12. Amperage / Wire Speed Adjustment
13. Voltage / Downslope / Arc Force
Adjustment
14. Inductance / Post Gas Control
15. Digital Display
16. TIG Torch Gas Connector
17. TIG Torch Trigger Connector
18. Plasma torch connector
17 18
17
16
