Fatigue Technology Inc. 401 Andover Park East Seattle, WA • USA 98188-7605 Tel: (206)246-2010 Fax: (206)244-9886
358856-REV K 5
3. Disconnect the air supply from the PowerPak when:
- Maintenance is to be performed.
- Tooling (mandrels, nosecaps, etc.) is to be installed.
- Hydraulic hose is disconnected.
- PowerPak is not in use.
Figure 2.0-2
Location of Air Disconnect
4. In the event of a ruptured or leaking hydraulic hose, IMMEDIATELY RELEASE THE TRIGGER AND
DISCONNECT THE AIR LINE from the PowerPak at the air coupler (see Figure 2.0-2). Never use your hands
to grasp a leaking hose under pressure. The force of escaping hydraulic fluid could cause serious injury. If
hydraulic oil should penetrate the skin, medical attention must be sought immediately.
5. DO NOT operate the puller or connect the hoses while any component is disassembled, missing, or loose.
Injury may occur.
6. Before operating the pump, ensure all hose couplings are tightened securely by hand. Do not overtighten the
connections. Couplings need only be tightened securely and leak-free. See Figure 3.1-2.
7. DO NOT use in potentially explosive atmospheres.
Air
IMPORTANT: FTI completed a risk assessment on this unit at our factory. Any modifications done
by a third party, or the final user are excluded from that risk assessment. As a result, modifications done
by a third party, or the final user nullify the CE marking.
To Next Page
