Fatigue Technology Inc. 401 Andover Park East Seattle, WA • USA 98188-2868 Tel: (206)246-2010 Fax: (206)244-9886
22 358856-REV K
Table 6.2-4
MB-30-H25 Parts List
Quantity
Description Reference Information Notes
1 1 2350-001 Housing
2 1 2184-006 Cylinder
3 1 2332-001 Barrel
10 1 2422-001 Locknut, Adapter
11 1 1046-058 O-Ring MS28775-224
12 1 1046-003 Ring, Backup MS28782-17
5/8-18 Threaded Adapter Assembly
Assembly, 25-foot Hydraulic Hose
19 1 2106-016 Assembly, 25-foot Air Hose (Female) IWAH-25 2, 3
20 1 2106-015 Assembly, 25-foot Air Hose (Male) IWAH-25 2, 3
21 12 2638-001 Tube, Heat Shrink 3-inch Piece
2
22 1 1009-185 Nosecap Warning Label
23 1 1009-184 Do Not Strike Label
30 1 1045-100 Spanner Wrench 34-358 4
31 1 2369-002 Pinwrench Assembly CBC-2-PW 4
32 1 2425-002 7/8-14 Threaded Adapter Assembly
4
33 1 6575-002 Pelican Kit Case with Foam FT-BX-21-16-10 4
Medium Brute Operator Manual
Notes:
1. Apply teflon tape to threads on piston (item number 4) after installing sleeve (item number 7) and prior to installing
threaded adapter (item number 17) and adapter locknut (item number 10). While installing sleeve (item number 7)
onto rod of piston, rotate piston until the threads pass the o-ring (item number 13). This will prevent the o-ring from
being damaged by the threads.
2. Hoses are to be fastened together using heat shrink tube, every two feet.
3. Install indicated items using teflon tape on threads.
4. Indicated items are included as part of assembly but are not installed into puller.
