PCC FTI MB-30 - Table 1.3-1 Medium Brute Specifications

Fatigue Technology Inc. 401 Andover Park East Seattle, WA • USA 98188-7605 Tel: (206)246-2010 Fax: (206)244-9886
358856-REV K 3
Table 1.3-1
Medium Brute Specifications
Model
Number
Maximum
Stackup
Length
Mandrel
Attachment
Weight*
(Excluding
Hoses)
Stroke Case Hose
MB-30
3.3 inch
(83.8 mm)
16.7 inch
(424.2 mm)
5/8-18 (Installed)
or 7/8-14 (Included)
13.0 lbs
(5.9 kg)
5.16 inch
(131 mm)
6575-002
Standard 10 foot
(3.0 m)
MB-30A
3.3 inch
(83.8 mm)
16.7 inch
(424.2 mm)
MB-CA-8 Chuck
13.4 lbs
(6.1 kg)
5.16 inch
(131 mm)
6575-002
Standard 10 foot
(3.0 m)
MB-30B
3.3 inch
(83.8 mm)
16.7 inch
(424.2 mm)
MB-CA-11 Chuck
13.4 lbs
(6.1 kg)
5.16 inch
(131 mm)
6575-002
Standard 10 foot
(3.0 m)
MB-30-H25
3.3 inch
(83.8 mm)
16.7 inch
(424.2 mm)
5/8-18 (Installed)
or 7/8-14 (Included)
13.0 lbs
(5.9 kg)
5.16 inch
(131 mm)
6575-002
Standard 25 foot
(7.6 m)
MB-30A-H25
3.3 inch
(83.8 mm)
16.7 inch
(424.2 mm)
MB-CA-8 Chuck
13.4 lbs
(6.1 kg)
5.16 inch
(131 mm)
6575-002
Standard 25 foot
(7.6 m)
MB-30C
3.3 inch
(83.8 mm)
16.7 inch
(424.2 mm)
5/8-18 (Installed)
or 7/8-14 (Included)
13.0 lbs
(5.9 kg)
5.16 inch
(131 mm)
N/A
Standard 10 foot
(3.0 m)
MB-30-V
3.3 inch
(83.8 mm)
16.7 inch
(424.2 mm)
5/8-18 (Installed)
or 7/8-14 (Included)
13.0 lbs
(5.9 kg)
5.16 inch
(131 mm)
6575-002
High-Vis 10 foot
(3.0 m)
MB-70
7.0 inch
(177.8 mm)
24.1 inch
(612.2 mm)
5/8-18 (Installed)
or 7/8-14 (Included)
16.1 lbs
(7.3 kg)
8.86 inch
(225 mm)
6575-003
Standard 10 foot
(3.0 m)
MB-70A
7.0 inch
(177.8 mm)
24.1 inch
(612.2 mm)
MB-CA-8 Chuck
16.5 lbs
(7.5 kg)
8.86 inch
(225 mm)
6575-003
Standard 10 foot
(3.0 m)
MB-70B
7.0 inch
(177.8 mm)
24.1 inch
(612.2 mm)
MB-CA-11 Chuck
16.5 lbs
(7.5 kg)
8.86 inch
(225 mm)
6575-003
Standard 10 foot
(3.0 m)
MB-70-H25
7.0 inch
(177.8 mm)
24.1 inch
(612.2 mm)
5/8-18 (Installed)
or 7/8-14 (Included)
16.1 lbs
(7.3 kg)
8.86 inch
(225 mm)
6575-003
Standard 25 foot
(7.6 m)
MB-70A-H25
7.0 inch
(177.8 mm)
24.1 inch
(612.2 mm)
MB-CA-8 Chuck
16.5 lbs
(7.5 kg)
8.86 inch
(225 mm)
6575-003
Standard 25 foot
(7.6 m)
MB-70-H20
7.0 inch
(177.8 mm)
24.1 inch
(612.2 mm)
5/8-18 (Installed)
or 7/8-14 (Included)
16.1 lbs
(7.3 kg)
8.86 inch
(225 mm)
6575-003
Standard 20 foot
(6.1 m)
MB-70-V
7.0 inch
(177.8 mm)
24.1 inch
(612.2 mm)
5/8-18 (Installed)
or 7/8-14 (Included)
16.1 lbs
(7.3 kg)
8.86 inch
(225 mm)
6575-003
High-Vis 10 foot
(3.0 m)
MB-70-H20-V
7.0 inch
(177.8 mm)
24.1 inch
(612.2 mm)
5/8-18 (Installed)
or 7/8-14 (Included)
16.1 lbs
(7.3 kg)
8.86 inch
(225 mm)
6575-003
High-Vis 20 foot
(6.1 m)
MB-10
1.3 inch
(33.0 mm)
12.7 inch
(322.6 mm)
5/8-18 (Installed)
or 7/8-14 (Included)
11.4 lbs
(5.2 kg)
3.16 inch
(80 mm)
6575-001
Standard 10 foot
(3.0 m)
MB-10A
1.3 inch
(33.0 mm)
12.7 inch
(322.6 mm)
MB-CA-8 Chuck
11.8 lbs
(5.4 kg)
3.16 inch
(80 mm)
6575-001
Standard 10 foot
(3.0 m)
MB-10B
1.3 inch
(33.0 mm)
12.7 inch
(322.6 mm)
MB-CA-11 Chuck
11.8 lbs
(5.4 kg)
3.16 inch
(80 mm)
6575-001
Standard 10 foot
(3.0 m)
BMB-10
1.0 inch
(25.4 mm)
15.7 inch
(398.8 mm)
BMB-CA-13 Chuck
19.2 lbs
(8.7 kg)
3.16 inch
(80 mm)
6575-002
Standard 10 foot
(3.0 m)
*A user-supplied suspension system may be required at the end use site. The requirement for a suspension system is based on
the end user’s workplace lifting and weight standards. A risk analysis for the suspension is necessary to maintain compliance to
end user’s standards or directives. All risks involved with the suspension of the Medium Brute are the responsibility of the end
user. User instructions and training regarding the
suspension system are the responsibility of the end user.
Nosecap Selection: The Medium Brute Puller Unit is compatible with standard nosecaps or extension nosecaps
(Refer to Section 2.3 of the FTI Tooling Catalog for more information).
Mandrel Selection: The Medium Brute Puller Unit is directly compatible with standard Type 2 or Type 5 threaded
mandrels (Refer to Section 2.3 of the FTI Tooling Catalog for more information).
