Fatigue Technology Inc. 401 Andover Park East Seattle, WA • USA 98188-2868 Tel: (206)246-2010 Fax: (206)244-9886
34 358856-REV K
Table 6.2-16
MB-10 Parts List
Item
Number
Quantity
Part
Number
Description Reference Information Notes
1 1 2350-001 Housing
2 1 2184-009 Cylinder
3 1 2332-004 Barrel
4
1
2405-004
Piston Assembly
1
5
1
2136-002
End Cap
6
1
5211-002
Handle Assembly
7
1
2349-001
Sleeve
1
8
1
2120-004
Lockring, Barrel
9
2
2120-002
Lockring, Cylinder
10 1 2422-001 Locknut, Adapter
11 1 1046-058 O-Ring MS28775-224
12 1 1046-003 Ring, Backup MS28782-17
13
1
1046-002
O-Ring
MS28775-212
14
1
1046-005
Ring, Backup
MS28782-28
15
1
1046-004
O-Ring
MS28775-325
16
1
1046-007
O-Ring
AS568-122 Buna, 90 Duro
17
1
2425-001
5/8-18 Threaded Adapter Assembly
1
18
1
2107-001
Assembly, 10-foot Hydraulic Hose
IWHH-10
2, 3
19 1 2106-002 Assembly, 10-foot Air Hose (Female) IWAH-10 2, 3
20 1 2106-001 Assembly, 10-foot Air Hose (Male) IWAH-10 2, 3
21 4 2638-001 Tube, Heat Shrink 3-inch Piece
2
22 1 1009-185 Nosecap Warning Label
23 1 1009-184 Do Not Strike Label
24
1
1187-105
Ear Protection Label
25
1
1187-106
Eye Protection Label
26
1
1187-107
Read Manual Label
27
2
1009-187
Medium Brute Label
28
1
1009-094
FTI Logo Label
29
1
1166-001
CE Label
30 1 1045-100 Spanner Wrench 34-358 4
31 1 2369-002 Pinwrench Assembly CBC-2-PW 4
32 1 2425-002 7/8-14 Threaded Adapter Assembly
4
33 1 6575-001 Pelican Kit Case with Foam FT-BX-20-15-9 4
34
1
2720-007
Medium Brute Operator Manual
4
Notes:
1. Apply teflon tape to threads on piston (item number 4) after installing sleeve (item number 7) and prior to installing
threaded adapter (item number 17) and adapter locknut (item number 10). While installing sleeve (item number 7)
onto rod of piston, rotate piston until the threads pass the o-ring (item number 13). This will prevent the o-ring from
being damaged by the threads.
2. Hoses are to be fastened together using heat shrink tube, every two feet.
3. Install indicated items using teflon tape on threads.
4. Indicated items are included as part of assembly but are not installed into puller.
