Peak Atlas DCA Pro User Guide June 2019 – Rev 1.7
Page 2
Want to use it now?
We understand that you want to use your Peak Atlas DCA Pro right
now. The unit is ready to go and you should have little need to refer to
this user guide, but please make sure that you do at least take a look at
the notices on page 5.
Contents Page
Introduction .................................................................................... 4
Important Considerations ............................................................... 5
Analysing Semiconductors - Standalone mode.............................. 6
Diodes ...................................................................................... 8
Zener Diodes ............................................................................ 9
Diode Networks ..................................................................... 10
LEDs ...................................................................................... 11
Bicolour LEDs (2-lead types) ................................................ 12
Bicolour LEDs (3-lead types) ................................................ 13
Bipolar Junction Transistors (BJTs)....................................... 14
Darlington Transistors............................................................ 18
Digital Transistors.................................................................. 21
Enhancement Mode MOSFETs ............................................. 22
Depletion Mode MOSFETs ................................................... 23
Enhancement Mode IGBTs.................................................... 24
Depletion Mode IGBTs.......................................................... 25
Junction FETs (JFETs)........................................................... 26
Thyristors (SCRs) and Triacs................................................. 28
Voltage Regulators................................................................. 29
Contents continued on next page…
