Peak Atlas DCA Pro User Guide June 2019 – Rev 1.7
Page 5
Important Considerations
Please observe the following guidelines:
• This instrument must NEVER be connected to powered
equipment/components or equipment/components with any
stored energy (e.g. charged capacitors). Failure to comply with
this warning may result in personal injury, damage to the
equipment under test, damage to your DCA Pro and invalidation
of the manufacturer’s warranty.
• The DCA Pro is designed to analyse semiconductors that are not
in-circuit, otherwise complex circuit effects will result in
erroneous measurements.
• Large voltage differences between true earth and your PC’s
USB port can result in damage. The device under test should
therefore have no path to earth or other supplies.
• Avoid rough treatment, hard knocks and extreme temperatures.
• This unit is not waterproof.
• Only use a good quality AAA Alkaline, NiMh or Lithium-Iron-
Disulphide cell. Input supply rated up to 1.9V.
