Peak Atlas DCA Pro User Guide June 2019 – Rev 1.7
Page 41
Appendix B – General Technical Specifications
Parameter
Min
Nom
Max
Units
Notes
Voltage Measurement (-12V to +12V)
Resolution
3.7
7.4
14.7
mV
1
Accuracy
±1.2% ±15mV
1
Voltage Drive (-12V to +12V)
Resolution
4.6
9.2
18.3
mV
1
Accuracy
±1.2% ±19mV
1
Current Measurement (0 to 20μA)
Resolution
0.01
0.02
0.04
μA
1
Accuracy
±1.7% ±0.14μA
1
Current Drive (0 to 20μA)
Resolution
0.01
0.02
0.04
μA
1
Accuracy
±1.7% ±0.14μA
1
Current Measurement (0 to 140μA)
Resolution
0.06
0.11
0.22
μA
1
Accuracy
±1.7% ±0.32μA
1
Current Drive (0 to 140μA)
Resolution
0.07
0.14
0.27
μA
1
Accuracy
±1.7% ±0.37μA
1
Current Measurement (0 to 1.2mA)
Resolution
0.45
0.90
1.79
μA
1
Accuracy
±1.7% ±1.9μA
1
Current Drive (0 to 1.2mA)
Resolution
0.56
1.12
2.23
μA
1
Accuracy
±1.7% ±2.4μA
1
Current Measurement (0 to 10mA)
Resolution
3.7
7.4
14.7
μA
1
Accuracy
±1.7% ±15μA
1
Current Drive (0 to 10mA)
Resolution
4.6
9.2
18.3
μA
1
Accuracy
±1.7% ±19μA
1
Load Current Measurement (0 to 12mA)
Resolution
6.6
13.1
26.2
μA
1,2
Accuracy
±1.7% ±27μA
1,2
Load Current Drive (0 to 12mA)
Resolution
8.2
16.4
32.7
μA
1,2
Accuracy
±1.7% ±33μA
1,2
General
Short circuit detection threshold
3.7
7.3
11.0
Ω
1
Peak current into short circuit
-15.5
15.5
mA
1
Peak voltage across open circuit
-13.5
13.5
V
1
Battery type
1 x AAA Alkaline / NiMh / Lithium-Iron-Disulphide
Battery voltage
1.0
1.5
1.9
V
USB current consumption
500mA peak active, <2mA sleep.
Dimensions (body)
103 x 70 x 20 mm
CS253.460
Notes for this table:
1. Between any 2 leads.
2. Used for transistor load current or PN V/I drive.
