2. Performance Indicator
Model
C-7100
C-7100S
C-7100A
Display
7 inch TFT
Keyboard Control
Silicone Buttons
Optical System
Single Beam
Holographic grating, 1200 lines/mm
Slit Width
2nm
1 nm
0.5,1,2,4 nm
Wavelength
Range
190 - 1100nm
Wavelength
Accuracy
±0.3nm
Wavelength
Repeatability
≤0.1nm
Photometric
Accuracy
0.2%T(0-100%T), ±0.002A(0-0.5A), ±0.004A(0.5-1A)
Photometric
Repeatability
≤0.15%T(0-100%T), 0.001A(0-0.5A), 0.002A(0.5-1A)
Stray Light
≤0.03%T@220nm,360nm
Stability
±0.001A/h@500nm
Photometric
Range
0-200%T, -0.3-3.0A, 0-9999C(0-9999F)
Baseline Flatness
±0.0015A(200-1000nm)
Noise
0.0003A@500nm
Working Mode
T,A,C,E
Wavelength
Setting
Automatic
Scanning Speed
High, Medium and Low
Detector
Solid Silicon Photodiode
Light Source
Tungsten Halogen/Deuterium Lamp
Data Output
RS232, USB(A), USB(A)
Processor
Cortex_M3, 120Mhz
Power
Requirements
AC 220V/50Hz
Shipping
Dimensions and
Weight
770*630*340mm, 27kg
