PeakTech 4145 User Manual

8.9 General Characteristics
Interface
Isolated USB Host interface
Copy saved file to PC from a U disk, then analyze it with upper computer
software.
Isolated LAN interface
For remote control of the Analyzer and measurement data transmission.
Screen
Color TFT LCD
Size
5.6 inch
Resolution
320×240
Brightness
Adjustable
Memory
Flash memory
128M
TF card
Standard 8Gbyte
Standards
Measurement method
IEC61000-4-30 S degree
Measurement performance
IEC61000-4-30 S degree
Power quality monitoring
EN50160
Flicker
IEC61000-4-15
Harmonic
IEC61000-4-7
Environment
Working temperature
0°~ 40°
Storage temperature
-20°~ 60°
Humidity
< 90% relative humidity
Safety
Complied with
IEC 61010-1
Safety Degree: 1000V CAT III / 600V CAT IV
Pollution Degree: 2
Maximum input voltage
600V CAT IV / 1000V CAT III
Maximum voltage at current
input
42Vpk
Mechanical
Dimension
262× 173 × 66 mm
Weight
1.6 kg
Power
Adapter input
90 ~ 264V
Adapter output
12V / 2 A
Battery
Rechargeable Ni-MH battery 7.2V 3.8Ah
Battery operating time
>7 hours
Battery charge time
5 hours
Specifications of optional current clamps
Model
Range
Turns ratio
Accuracy
Size (mm)
P 4145-5A
5A
10mV/A
±0.2%
8mm
P 4145-50A
50A
10mV/A
±0.2%
8mm
P 4145-100A
100A
1mV/A
±0.2%
13mm
P 4145-1000A
1000A
1mV/A
±1.0%
52mm
P 4145-3000A
3000A
65mV/1000A
±1.0 (±2% position error)
160mm
