6.6. Setting up the Analyzer
At power-on, a welcome screen is displayed that shows settings currently in use. Check if the Date and
Time of the system clock are correct. Also the wiring configuration must match the configuration of the
power system to be checked. The 【SETUP】 key accesses menus to view and change Analyzer
settings.
The settings are grouped in four functional sections which are explained respectively as below:
General settings: wiring configuration, nominal frequency, nominal voltage, current clamps,
current range and language.
User preference: date and time, LAN interface.
Limits settings: For recall, save and definition of the limits for power quality monitoring.
Setup interface
Press 【SETUP】 key to access to setup interface, use up/down arrow keys to select options to be
adjusted, then press left/right arrow keys to adjust. Settable options:
After selecting wiring configuration, press 【ENTER】 key to access to wiring
configuration interface. Press【F4】to confirm selection.
Adjust nominal frequency, after selecting nominal frequency, switch between
preset 50Hz and 60Hz with left/right arrow keys.
Adjust nominal voltage, after selecting nominal voltage, press 【ENTER】key
to access to voltage configuration interface and press 【F5】key to confirm
your selected nominal voltage.
Select language then press left/right arrow keys to switch between Chinese and
English.
Select the zooming setup and press 【ENTER】 key to access to set up
interface. Current clamp type and zoom of voltage/current are selectable. Press
【F5】to confirm the setting.
Available function keys:
Access to user preference interface, configure data, time, LAN
interface etc.
Access to calibration interface, calibrate the Analyzer.
Configure limits value parameters for power quality monitoring.
Access to menu interface.
-52-
