peerless-AV XTREME - (RS-232 C) Serial Control of the Display

24
2018-05-30 #:180-9116-7 (2020-08-04)
Menu:
Right:
OK:
Down:
Up:
Left:
Source:
(1):
(2):
(3):
(4):
(5):
(6):
(7):
(8):
(9):
(0):
Exit:
Power On:
󰀨
󰀨
Volume +:
Volume -:
Channel +:
Channel -:
Surround:
CC:
EPG:
Info:
MTS:
Mute:
Sleep:
AV:
VGA:
HDMI Toggle:
HDMI1:
HDMI2:
HDMI3:
DisplayPort:
TV:
DTV:
Component:
USB:
PMODE:
Zoom:
SMODE:
VOL 0%:
VOL 25%:
VOL 50%:
VOL 75%:
VOL 100%:
Brightness 0%:
Brightness 25%:
Brightness 50%:
Brightness 75%:
Brightness 100%:
Dash:
Channel Fav List:
Channel List:
Channel Return:
A0, F0, 55, FF, 4E, B1
A0, F0, 55, FF, 05, FA
A0, F0, 55, FF, 02, FD
A0, F0, 55, FF, 0D, F2
A0, F0, 55, FF, 17, E8
A0, F0, 55, FF, 0C, F3
A0, F0, 55, FF, 01, FE
A0, F0, 55, FF, 42, BD
A0, F0, 55, FF, 43, BC
A0, F0, 55, FF, 0F, F0
A0, F0, 55, FF, 1E, E1
A0, F0, 55, FF, 1D, E2
A0, F0, 55, FF, 1C, E3
A0, F0, 55, FF, 18, E7
A0, F0, 55, FF, 45, BA
A0, F0, 55, FF, 4C, B3
A0, F0, 55, FF, 56, A9
A0, F0, 55, FF, 1B, E4
A0, F0, 55, FF, AE, 51
A0, F0, 55, FF, AD, 52
A0, F0, 55, FF, 0B, F4
A0, F0, 55, FF, 0A, F5
A0, F0, 55, FF, 40, BF
A0, F0, 55, FF, 55, AA
A0, F0, 55, FF, 5A, A5
A0, F0, 55, FF, C7, 38
A0, F0, 55, FF, 44, BB
A0, F0, 55, FF, 49, B6
A0, F0, 55, FF, 50, AF
A0, F0, 55, FF, 11, EE
A0, F0, 55, FF, 14, EB
A0, F0, 55, FF, 53, AC
A0, F0, 55, FF, ED, 12
A0, F0, 55, FF, EA, 15
A0, F0, 55, FF, EC, 13
A0, F0, 55, FF, DE, 21
A0, F0, 55, FF, DF, 20
A0, F0, 55, FF, E0, 1F
A0, F0, 55, FF, E4, 1B
A0, F0, 55, FF, E8, 17
A0, F0, 55, FF, E9, 16
A0, F0, 55, FF, E7, 18
A0, F0, 55, FF, 57, A8
A0, F0, 55, FF, 4B, B4
A0, F0, 55, FF, 51, AE
A0, F0, 55, FF, 5B, A4
A0, F0, 55, FF, 20, DF
A0, F0, 55, FF, 21, DE
A0, F0, 55, FF, 22, DD
A0, F0, 55, FF, 23, DC
A0, F0, 55, FF, 24, DB
A0, F0, 55, FF, 25, DA
A0, F0, 55, FF, 26, D9
A0, F0, 55, FF, 27, D8
A0, F0, 55, FF, 28, D7
A0, F0, 55, FF, 29, D6
A0,F0, 55, FF, 2E, D1
A0, F0, 55, FF, 1A, E5
A0, F0, 55, FF, 59, A6
A0, F0, 55, FF, 15, EA
COM Settings
Baud Rate 38400
Data Bits 8
Parity None
Stop Bits 1
(RS-232C) Serial Control Of The Display
Attach an RS-232C cable (straight through type) to the supplied D-Sub RS-232C to utilize serial
control function. Control via RS232 should only be utilized by experts familiar with RS232 programing.
